In this blog post, I’ll be decrypting the mathematics behind the gradient descent optimizer. The equation of a best fit line as you all know is y = mx + c and the y value is going to change for different values of x, so let’s write that down as an equation.




Now we need to find the error margin between the actual y value and the predicted y value. To do that we use the following equation. Where y is the actual value and y hat is the predicted value.




The loss, as stated earlier, is calculated by summing the squares of the error deltas together.




Substituting the standard equation of a best fit line into the loss function, we obtain the following equation.




Further substitution gives us the following equation of the loss function.




The ultimate goal of gradient descent in our linear regression model is to minimize the loss value obtained from our loss function for different values of m and c during training. Before we derive our next equation, let us make m and c equal to M independently, so c = M and m = M this will make our derivation much simpler. From the equation above we can tell that any changes made to m or c will have a direct impact on the loss, since we generalized and equated c and m to M independently, any changes to M will impact the loss value, letting the loss value equal L. Since our loss function is essentially the sum of squared error deltas, the graph of L against M would give us an inverse parabolic curve. The loss is 0 or near 0 at the bottom of the curve so we need to make our way there by adjusting the values of m and c but using brute force will take a very, very long time, so we use gradient descent.

First, we need to have a derivative of the loss function so that we can see if we need to increase the value of M or decrease the value of M. The goal is to make the derivative of the loss function equal a value close to 0. Since we are changing the value of M individually as we work, the derivative is a partial derivative.




From the derivative of our loss function, we can tell if we need to increase or decrease the value of M. If the derivative is positive, going uphill, increasing the value of M would increase the loss, so we need to decrease it. If the derivative is negative, going downhill, increasing the value of M would decrease the loss. Now that we know which way to go we need to make a move. To update the value of M we use the following formula.




In the above formula, alpha is the learning rate, the argument of the tf.train.GradientDescentOptimizer class. This process of updating and calculating the loss happens till the derivative of the loss function is as close to 0 as possible. In our model, m and c are updated independently and simultaneously. This is how gradient descent works.
